Introduction:It converts RCA (AV, composite, CVBS) signals into HDMI signals so you can watch your video on a modern TV with HDMI ports. The analog to digital conversion in this module employs 10 bits maximal 162MSPS sampling, black/white level expansion, color transition improvement, dynamic range expansion, blue stretch , auto-detect and auto-convert the composite signal to 1080p(60HZ) output. Making video come alive, delivering the sharpest, most realistic HD visuals available. Specifications: 1. Input ports: 1xRCA (Yellow, White, Red), USB power 2. Output ports: 1xHDMI(standard) 3. NTSC/PAL compatible 4. Composite input: PAL, NTSC3.58, NTSC4.43, SECAM, PAL/M, PAL/N 5. HDMI output: 1080p/60Hz, 720p/60Hz 6. Dimensions (mm): 66(D)x55(W)x20(H) 7. Weight (g): 40g 8. Power: USB Port Features: No need to install drivers, portable, flexible, plug and play. Support PAL, NTSC3.58, NTSC4.43, SECAM, PAL/M, PAL/N standard TV formats input. Output the audio synchronization with video. Can be displayed on Moniter/ TV with 1920x1080@60Hz High bandwidth capability NOTE:May experience less than three second lag.Will not convert audio only. , Important:For converter to function properly all cables must be connected and in use (yellow: video, white: left audio, and red: right audio).Supported audio format: 2 channel analog audio, does not support 3D. Package content: 1xAV to HDMI Converter 1xUSB Cable 1xUser Manual NOTE:Video signal transfer only, can't improve the video quality
